Modi Adjustable Heated Towel Rail 900mm - Polished Stainless
SKU: 17041
Free Delivery on Orders Over £500!
Modi Adjustable Heated Towel Rail 900mm - Polished Stainless
SKU: 17041
Free Delivery on Orders Over £500!
Complete with...
£15.99
12V Transformer 105W
Product Details
The 12V Transformer 105W is required to power our heated towel rails and ladders. Installed between the power supply and the heated towel rail or ladder, the transformer connects to the 230V input and delivers regulated power through the output connection.
This transformer must be purchased separately when installing our heated towel rails and ladders.
Please Note:
– This product must be installed by a licensed electrician in accordance with IET Wiring Regulations (BS 7671) and current local and national building regulations. The installation guide must be referred to before installation.
– This transformer allows for the operation of 12 V AC and draws the wattage required. It is connected via a safety isolating transformer (SELV) with a constant 12 V AC output.
Features:
– Operating Voltage: 230v 50Hz
– Maximum Load Rating: 105W
– Maximum Current Rating: 230V AC: 0.46A / 11.5V AC: 9.1A
– Applicable Safety Standard: EN 61347-1, EN 61347-2-2, EN 61547, EN 55015 & EN 61000-3-2
– Short circuit protection – IP20
Product Details
The Modi Adjustable Heated Towel Rail is a wall-mounted unit featuring a 12V heated vertical mounting rail and an adjustable top fixing. This design allows for maximum customisation and flexibility, with the added benefit of warm towels — perfect for cooler climates.
As with the Modi Adjustable range, this heated towel rail can be adjusted to attain the perfect length for your space. Its simple and sleek design makes it an excellent choice for both retrofit and new installations.
Please Note:
– This product must be installed by a licensed electrician in accordance with IET Wiring Regulations (BS 7671) and current local and national building regulations.
– This heated towel rail is electric and requires a transformer to function. The transformer is not included and must be purchased separately here.
– This heated towel rail operates on 12 V AC/DC and draws 20W. It must be connected via a safety isolating transformer (SELV) with a constant 12 V AC/DC output.
– If you are installing more than one heated towel rail, please consult your electrician as transformer requirements will differ.
Features:
– 304 stainless steel construction offers durability for indoor and commercial use.
– Adjustable fixing points — perfect for retrofit applications.
Dimensions:
– Length: 900mm
– Width: 36mm
– Projection: 93mm off the wall
Browse our heated towel rail range, or explore our complete towel rail range.
Product Features
304 Stainless Steel
Adjustable wall fixing points
Wall Mounted
Material
Construction
304 Stainless Steel
Finish/Coating
(PVD) Brushed Nickel - ABI’s Heat Shield – Industrial Grade Electro Colouring System (Physical Vapour Deposition)
*We implement strict quality procedures to minimise colour variations, however we acknowledge that there may be minor differences between batches. We encourage you to check over your items once received to ensure that you are satisfied with the finish. Should you receive anything of concern, our team is here to help!
For more information on our finish quality
Specifications
| SKU | 17041 |
| Weight | 1.8kg |
| Brand | ABI Interiors |
| Dimensions | Length: 900mm Projection: 93mm Handle Diameter: 36mm |
| Hardware | Mounting hardware included |
| Construction | 304 Stainless Steel |
| Finish/Coating | (PVD) Brushed Nickel - ABI’s Heat Shield – Industrial Grade Electro Colouring System (Physical Vapour Deposition) |
| Dimensions (mm) | Length: 80mm Width: 36mm Height: 40mm |
| Compatibility | The Modi Towel Hooks are compatible with our Modi Adjustable Heated Towel Rails |
| What's In The Box | 2 x Hooks 2 x Grub Screws |
Specification guides can be found under the Downloads tab.
Downloads
Product Documents
| Modi Adjustable Heated Towel Rail 900mm - Specification |  |
Bim Files
| View Product |  |
| View Collection | |
| View Library | |
| PRODUCT DESCRIPTION | RESIDENTIAL WARRANTY | NON-RESIDENTIAL WARRANTY | OUTDOOR WARRANTY | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Name & Finish | SKU | Structure | Finish | Cartridge | Other | Structure | Finish | Cartridge | Other | Structure | Finish | Cartridge | Other |
| Modi Adjustable Heated Towel Rail 900mm - Polished Stainless | 17041 | Lifetime | 2 | - | 2 | Lifetime | 2 | - | 2 | - | - | - | - |
Product FAQs
How does the Modi Adjustable Heated Towel Rail function?
The top collar is fully adjustable, allowing you to customise the fixing points along the towel rail to your desired distance. The bottom collar is fixed and contains the electrical components required to heat the towel rail. Our heated towel rails are electric and require a 12V DC transformer. This will need to be purchased from an alternative supplier.
How should I clean this product?
We recommend cleaning with soap and water or a mild liquid detergent. For comprehensive cleaning instructions, please refer to our Care Guide.
Can I install the Modi Adjustable Heated Towel rail myself?
The Modi Adjustable Heated Towel rail must be installed by a licensed electrician who adheres to local regulations. The regulations in your area may affect the location where this product can be installed in your bathroom.
Is the transformer included with this product?
No, the transformer is not included and must be sourced separately. This heated towel rail operates on 12 V AC/DC and draws 20W. It must be connected via a safety isolating transformer (SELV) with a constant 12 V AC/DC output. We recommend consulting your licensed electrician regarding transformer requirements.
