Cross Assembly Taps & Spout Set - Tumbled Aged Brass
SKU: 20052
T43731(v)| WELS: 5 Star | Litres / min: 6
Free Delivery on Orders Over £500!
Cross Assembly Taps & Spout Set - Tumbled Aged Brass
SKU: 20052
T43731(v)| WELS: 5 Star | Litres / min: 6
Free Delivery on Orders Over £500!
Product Details
Infiniti Technology is all about interchangeable tapware. It has been specifically manufactured to provide the option to have your finish and handle style changed after installation without compromising your existing waterproofing or tiling.
Enabling superb versatility, our Assembly Taps come in three different handle designs, which include the minimalist Barre, the vintage Cross and the smooth rounded single Milani hand mixer.
Please Note:
– The uncoated, raw construction of this product means it will naturally oxidise, causing it to age and change over time. Environmental factors and the installation location will influence how fast the product oxidises and the aged look achieved. As a result, there will be a slight variation in the finish of each product, so no two products appear exactly the same, helping you achieve individuality in your design. The product may arrive with a natural patina already.
Includes:
– Handle Kit
– Wall Mounted Spout
– In-Wall Breech
Features:
– Precise Temperature Control
– Easy-to-clean solid brass construction suitable for indoor and outdoor use
– Tumbled with small stones to create a unique finish and aged look
– Uncoated brass naturally patinas and changes over time
Product Features
Solid Brass
Artisanal Texture
Precise Pressure and Temperature Control
Material
Construction
Solid Brass
*We implement strict quality procedures to minimise colour variations, however we acknowledge that there may be minor differences between batches. We encourage you to check over your items once received to ensure that you are satisfied with the finish. Should you receive anything of concern, our team is here to help!
For more information on our finish quality
Specifications
| SKU | 20052 |
| Weight | 1.5kg |
| Brand | ABI Interiors |
| Construction | Solid Brass |
| Assembly Tap Dimensions (mm) | Tap Handle Length: 70mm Backplate Diameter: 54mm |
| Spout Dimensions (mm) | Reach: 200mm Backplate Diameter: 60mm |
| What's In The Box | In-Wall Kit (required for rough-in): 2 x Spindles 2 x Locking Nuts Handle Kit (required for fit-off): 2 x Sleeves 2 x Grub Screws 2 x Backplates 2 x Handle s 1 x Allen Key Wall Mounted Spout (required for fit-off): 1 x Backplate 1 x Spout |
| Lead Free Compliant | Yes - Compliant with the Lead-Free requirements of the National Construction Code Volume Three |
| Mount Type | Wall-mounted |
Specification guides can be found under the Downloads tab.
Downloads
Product Documents
| Cross Assembly Taps & Spout Set - Specification |  |
| TMV Placement - Specification | |
Bim Files
| View Product |  |
| View Library | |
Tumbled Aged Brass
The uncoated, raw construction of this product means it will naturally oxidise, causing it to age and change over time. Environmental factors and the installation location will influence how fast the product oxidises and the aged look achieved. As a result, there will be a slight variation in the finish of each product, so no two products appear exactly the same, helping you achieve individuality in your design. The product may arrive with a natural patina already.
| PRODUCT DESCRIPTION | RESIDENTIAL WARRANTY | NON-RESIDENTIAL WARRANTY | OUTDOOR WARRANTY | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Name & Finish | SKU | Structure | Finish | Cartridge | Other | Structure | Finish | Cartridge | Other | Structure | Finish | Cartridge | Other |
| Cross Assembly Taps & Spout Set - Tumbled Aged Brass | 20047 | Lifetime | 15 | Lifetime | 2 | Lifetime | 15 | Lifetime | 2 | Lifetime | 5 | Lifetime | 2 |
5
Water Rating
6
Litres Per Minute
T43731(v)
Registration Number
| Description | Valve Rates | ||||||
|---|---|---|---|---|---|---|---|
| Product | Parts Used Where Applicable | Min Bar | 0.5 Bar | 1.0 Bar | 2.0 Bar | 3.0 Bar | |
| Cross Assembly Taps & Spout Set - Tumbled Aged Brass | - |
0.5 | 7.8 | 10.8 | 15.4 | 18.8 | |
Product FAQs
Can I swap out my handle design or finish after installation if I change my mind without compromising my tiles or damaging the waterproofing?
Yes, our Infiniti Technology allows the flexibility and the convenience to have your handles swapped out after installation of the rough-in without damaging waterproofing or tiling.
Is a breech included with my purchase?
No, a breech is not included with your Assembly Taps purchase.
What parts are included with my purchase?
You will receive the following:
In-Wall Kit (required for rough-in):
2 x Spindles
2 x Locking Nuts
Handle Kit (required for fit-off):
2 x Sleeves
2 x Grub Screws
2 x Backplates
2 x Handle s
1 x Allen Key
Wall Mounted Spout (required for fit-off):
1 x Backplate
1 x Spout
